Features:

Main features

1. Imported dual servo motors, high precision, decreased the mechanical driving parts and malfunction.

2. Touch screen control the parameters (nails distance, nails qty/type, back baffles), changing fast and convenient.

3. Back electrical baffle adopt stepper motor, accurate and fast.

4. The complete stitching head adopts special steel with precise processing.

5. Carton sizes and nails distance changing time need 1 minute, save more time.

6. Can stitch intensive nails, single nail, double rows nail, finish in one time.

7. Front paper feeding part is automatic counting, settled with photoelectric sensor, can lift up automatically when feed paper.

8. Last section has automatic counting function, finished cartons can be piled as per the pre-set qty (1~99) and convey out for easy packing.

9. Will warn automatically when the brass wires finished.

Details of The Machine

The paper feeder

Paper feeding part adopts frequency conversion timing belt, vacuum adsorption front, equipped with side flapping device, ensure that the feed is not skew.

The folder part

The folding characteristics is mounted with creasing wheel, carries on second time of creasing. This makes the folding of the carton more beautiful. This machine before stitching box in the folded part have a shaping device, folding the carton before stitching, ensure there is no scissors difference.

The correction device

The correcting section adopts the servo motor to correction , then synchronous belt transport the box into stitching section, ensure no scissors difference.

The stitching box part

Stitching head adopts special materials, durable and not easy to damage speeds up to 800/1000 nails per minute, the machine features is that the head adopt servo motor direct drive, speed is stable and accurate. Can do single nail, double nails, head and tail stitch, strengthening the middle stick operation. A nail line using 2 spools 20 kilograms of automatic wire feeding, reduce the time for changing wire spool.

Packaging & Delivery
Packaging Details:
We usually packed this machine covered by plastic film.
Delivery Detail:
Within 30 days after we got the deposit.
